P3 Series

P3 hose and braid represent a new generation of products manufactured using an innovative production process which allows for longer lengths, uniformity of corrugations and consistency of pitch.

The series promises a bright, clean finish with a high coverage braid that provides optimum working pressures and maximum protection. Penflex carefully packages P3 on durable reels for shipment by air, truck or ocean.

Benefits

Lightweight construction
Easy installation
Made in accordance with ISO 10380
Available in compressed pitch with higher corrugation count for greater flexibility
DNV GL certified
Clean ID option

Technical Specifications

Construction: Annular hose with a standard pitch
Hose material: 316L and 321 stainless steel
Braid material: 304L and 316L
Other alloys available upon request
Hose sizes: 1/4″ through 2″


Nom.I.D. (in.)	Part Number	Braid Layers	Braid Construction	Braid Coverage (%)	Nom.O.D. (in.)	Maximum Pressure @70°F (PSIG)		Bend Radius (in.)		Weight per Foot (LB.)
Nom.I.D. (in.)	Part Number	Braid Layers	Braid Construction	Braid Coverage (%)	Nom.O.D. (in.)	Working	Nominal Burst	Dynamic	Static	Weight per Foot (LB.)
	30xx-004	0			0.38	72	----			0.04
1/4”	P3-H30xx-B30xx-004	1	24 x 6 x .010	95	0.43	2,360	9,440	3.15	1.10	0.10
	P3-H30xx-2B30xx-004	2			0.48	2,832	11,328			0.15
	30xx-005	0			0.48	72	----			0.06
5/16”	P3-H30xx-B30xx-005	1	24 x 7 x .010	92	0.53	1,647	6,588	4.85	1.23	0.12
	P3-H30xx-2B30xx-005	2			0.58	1,976	7,904			0.18
	30xx-006	0			0.56	72	----			0.07
3/8”	P3-H30xx-B30xx-006	1	24 x 7 x .012	93	0.62	1,639	6,556	5.08	1.52	0.16
	P3-H30xx-2B30xx-006	2			0.68	1,967	7,868			0.25
	30xx-008	0			0.66	72	----			0.08
1/2”	P3-H30xx-B30xx-008	1	24 x 8 x .012	92	0.72	1,225	4,900	5.47	1.75	0.18
	P3-H30xx-2B30xx-008	2			0.78	1,470	5,880			0.28
	30xx-010	0			0.85	71	----			0.13
5/8”	P3-H30xx-B30xx-010	1	36 x 6 x .014	93	0.92	1,200	4,800	6.28	2.21	0.28
	P3-H30xx-2B30xx-010	2			0.99	1,440	5,760			0.44
	30xx-012	0			1.05	43	----			0.17
3/4”	P3-H30xx-B30xx-012	1	36 x 8 x .014	96	1.12	1,034	4,136	6.58	2.65	0.38
	P3-H30xx-2B30xx-012	2			1.19	1,241	4,964			0.59
	30xx-016	0			1.27	43	----			0.24
1”	P3-H30xx-B30xx-016	1	48 x 7 x .014	95	1.34	796	3,184	7.50	3.33	0.48
	P3-H30xx-2B30xx-016	2			1.41	955	3,820			0.72
	30xx-020	0			1.62	43	----			0.38
1-1/4”	P3-H30xx-B30xx-020	1	48 x 9 x .014	95	1.69	600	2,400	10.20	4.10	0.70
	P3-H30xx-2B30xx-020	2			1.76	720	2,880			1.01
	30xx-024	0			1.95	28	----			0.50
1-1/2”	P3-H30xx-B30xx-024	1	48 x 9 x .016	94	2.03	557	2,228	11.75	5.08	0.90
	P3-H30xx-2B30xx-024	2			2.11	668	2,672			1.31
	30xx-032	0			2.38	28	----			0.61
2”	P3-H30xx-B30xx-032	1	48 x 9 x .020	94	2.48	570	2,280	12.55	6.27	1.25
	P3-H30xx-2B30xx-032	2			2.58	684	2,736			1.88

Download P3 Spec Sheet (US)

Download P3 Spec Sheet (Metric)

P3 Compressed (US)

P3 Compressed (Metric)

Download Full Metal Hose Catalog

CL3: Clean ID Hose

Given the cleanliness requirements for cryogenic and vacuum applications, we wondered if it was possible to eliminate the need for cleaning processes with a more precise manufacturing process.

For Penflex, this meant removing the internal tooling and, with it, the need for lubrication oil. By re-working the way we make tube and reducing the amount of power required to bring the tube into the corrugation headers, we were able to do just that!

A greater level of precision now allows us to offer stainless steel hose with a truly clean inside. CL3 features the same geometry as P3, delivering the same thin-wall construction with low corrugation profile and high pitch count for a very flexible hose. CL3 is currently available in sizes ½” – 1”.
