1400 Series

Penflex 1400 Series heavy-wall stainless steel hose is designed for extreme pressure applications. Its heavy-duty braid is constructed to sustain the highest working pressures and provide maximum protection to the inner core. The extra heavy-wall of the hose allows for longer service life in a wide variety of corrosive environments.

Benefits

Heaviest-weight construction
Superior corrosion resistance
Highest pressure ratings

Technical Specifications

Construction: Annular hose with a standard pitch
Hose material: 316L stainless steel
Braid material: 304 stainless steel
3 or 4 layers of braid
Other alloys available upon request
Hose sizes: 1/2″ through 4″


Nom.I.D. (in.)	Part Number	Braid Layers	Braid Construction	Nom. O.D. (in.)	Maximum Pressure @ 70ºF (PSIG)		Bend Radius (in.)		Weight per Foot (Lb.)
Nom.I.D. (in.)	Part Number	Braid Layers	Braid Construction	Nom. O.D. (in.)	Working	Nominal Burst	Dynamic	Static	Weight per Foot (Lb.)
1/2"	1416-3HTSB-008	3	24 x 7 x .020	1.2	4,000	16,000	14	7	1.1
3/4"	1416-3HTSB-012	3	48 x 4 x .024	1.65	5,000	20,000	15	7.5	2
1"	1416-3HTSB-016	3	48 x 5 x .024	1.92	4,200	16,800	16	8	2.7
1-1/2"	1416-3HTSB-024	3	48 x 7 x .024	2.55	2,750	11,000	24	12	4.15
2"	1416-3HTSB-032	3	48 x 8 x .024	3.07	2,180	8,720	40	20	5
3"	1416-3SHB-048	3	72 x 9 x .025	4.22	1,250	5,000	84	32	8.7
4"	1416-4SHB-064	4	72 x 10 x .024	5.27	1,250	5,000	112	52	10.48
